Rx 5600xt keep crashing after few hours of mining on most miners

AMD Cards
#1

Hello, i have a rig that keep crashing because of this Rx 5600xt it mines without problem for hours then, suddenly it slightly underclocks the core then crashes, and temperature is okay (Core 50c-52c) and (80c-82c) for the memory, and for some reason it refuses all the memory undervolt (VDDCI and MVDD) if i change it from default it will crash after few minutes, the only one i can touche is the vdd and i set it to 720mv, if i rise it it will run hotter and give lower hashrates and crashes eventually and i’m running the stock firmware, and i tried a modified one but it only gives 25Mh/s, what do you think guys, thank you.
here’s some logs:

.[0m.[96m
.[0m.[96m .[0m.[96mName .[0m.[96m Speed.[0m.[96m Pool.[0m.[96m Shares.[0m.[96m Best.[0m.[96m Eff…[0m.[96m
.[0m.[96m .[0m.[96m .[0m.[96m Mh/s.[0m.[96m Mh/s.[0m.[96m A/S/Hw.[0m.[96m Share.[0m.[96m Mh/s/W.[0m.[96m
.[0m.[96mGPU 0 .[0m.[96mGTX 1080 Ti.[0m.[96m 43.62.[0m.[96m 47.23.[0m.[96m 63/0/0.[0m.[96m 1.5T.[0m.[96m 0.227.[0m.[96m
.[0m.[96mGPU 1 .[0m.[96mGTX 1080 Ti.[0m.[96m 42.70.[0m.[96m 42.73.[0m.[96m 57/0/0.[0m.[96m 3.7T.[0m.[96m 0.206.[0m.[96m
.[0m.[96mGPU 2 .[0m.[96mRTX 2060 .[0m.[96m 32.22.[0m.[96m 27.74.[0m.[96m 37/0/0.[0m.[96m 2.5T.[0m.[96m 0.487.[0m.[96m
.[0m.[96mGPU 3 .[0m.[96mRX 5600 XT .[0m.[96m 40.52.[0m.[96m 35.98.[0m.[96m 48/0/0.[0m.[96m 5.3T.[0m.[96m 0.420.[0m.[96m
.[0m.[96m---------------------------
.[0m.[96mTotal .[0m.[96m .[0m.[96m 159.05.[0m.[96m 153.67.[0m.[96m 205/0/0.[0m.[96m 5.3T.[0m.[96m 0.283.[0m.[96m
.[0m.[96m
.[0m.[96m .[0m.[96m Power.[0m.[96m CCLK.[0m.[96m MCLK.[0m.[96m Core.[0m.[96m Junc.[0m.[96m Mem.[0m.[96m Fan.[0m.[96m
.[0m.[96m .[0m.[96m W.[0m.[96m MHz.[0m.[96m MHz.[0m.[96m Temp.[0m.[96m Temp.[0m.[96m Temp.[0m.[96m Pct.[0m.[96m
.[0m.[96mGPU 0 .[0m.[96m 192.0.[0m.[96m 2062.[0m.[96m 5005.[0m.[96m 44.[0m.[96m 58.[0m.[96m N/A.[0m.[96m 65.[0m.[96m
.[0m.[96mGPU 1 .[0m.[96m 206.8.[0m.[96m 2012.[0m.[96m 4865.[0m.[96m 56.[0m.[96m 70.[0m.[96m N/A.[0m.[96m 94.[0m.[96m
.[0m.[96mGPU 2 .[0m.[96m 65.7.[0m.[96m 1050.[0m.[96m 7787.[0m.[96m 42.[0m.[96m 58.[0m.[96m 58.[0m.[96m 67.[0m.[96m
.[0m.[96mGPU 3 .[0m.[96m 96.1.[0m.[96m 978.[0m.[96m 890.[0m.[96m 50.[0m.[96m 55.[0m.[96m 82.[0m.[96m 72.[0m.[96m
.[0m.[96m---------------------------
.[0m.[96mTotal .[0m.[96m 560.6.[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m
.[0m.[96m---------------------------------------------
.[0mAverage speed (10s): 43.61 Mh/s | 42.69 Mh/s | 32.22 Mh/s | 40.55 Mh/s Total: 159.07 Mh/s
.[93mNew job received: 0x45f790 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0x23f132 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0x93896e Epoch: 489 Difficulty: 17.45G
.[0mAverage speed (10s): 43.61 Mh/s | 42.69 Mh/s | 32.22 Mh/s | 40.51 Mh/s Total: 159.03 Mh/s
.[93mNew job received: 0xc86d1f Epoch: 489 Difficulty: 17.45G
.[0mAverage speed (10s): 43.61 Mh/s | 42.71 Mh/s | 32.22 Mh/s | 40.55 Mh/s Total: 159.09 Mh/s
.[93mNew job received: 0x98eb50 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xc457ad Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xd5957a Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xd50f51 Epoch: 489 Difficulty: 17.45G
.[0mAverage speed (10s): 43.62 Mh/s | 42.69 Mh/s | 32.22 Mh/s | 40.51 Mh/s Total: 159.05 Mh/s
.[93mNew job received: 0x2f6af1 Epoch: 489 Difficulty: 17.45G
.[0mAverage speed (10s): 43.62 Mh/s | 42.69 Mh/s | 32.22 Mh/s | 19.46 Mh/s Total: 137.99 Mh/s
.[93mNew job received: 0x4fae8a Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0x8bc7da Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xe3a7dd Epoch: 489 Difficulty: 17.45G
.[0mAverage speed (10s): 43.62 Mh/s | 42.69 Mh/s | 32.22 Mh/s | 0.00 Mh/s Total: 118.53 Mh/s
.[93mNew job received: 0x3a0365 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xc17d75 Epoch: 489 Difficulty: 17.45G
.[0m.[96m---------------------------------------------
.[0m.[96mStatistics (21:34:22); Uptime: 6h 29m 2s
.[0m.[96mThe api is active on port 44444
.[0m.[96mMining: Ethash
Connected to: //////
.[0m.[96m
.[0m.[96m .[0m.[96mName .[0m.[96m Speed.[0m.[96m Pool.[0m.[96m Shares.[0m.[96m Best.[0m.[96m Eff…[0m.[96m
.[0m.[96m .[0m.[96m .[0m.[96m Mh/s.[0m.[96m Mh/s.[0m.[96m A/S/Hw.[0m.[96m Share.[0m.[96m Mh/s/W.[0m.[96m
.[0m.[96mGPU 0 .[0m.[96mGTX 1080 Ti.[0m.[96m 43.62.[0m.[96m 47.10.[0m.[96m 63/0/0.[0m.[96m 1.5T.[0m.[96m 0.226.[0m.[96m
.[0m.[96mGPU 1 .[0m.[96mGTX 1080 Ti.[0m.[96m 42.69.[0m.[96m 42.62.[0m.[96m 57/0/0.[0m.[96m 3.7T.[0m.[96m 0.207.[0m.[96m
.[0m.[96mGPU 2 .[0m.[96mRTX 2060 .[0m.[96m 32.22.[0m.[96m 27.66.[0m.[96m 37/0/0.[0m.[96m 2.5T.[0m.[96m 0.487.[0m.[96m
.[0m.[96mGPU 3 .[0m.[96mRX 5600 XT .[0m.[96m 23.65.[0m.[96m 35.89.[0m.[96m 48/0/0.[0m.[96m 5.3T.[0m.[96m 0.493.[0m.[96m
.[0m.[96m---------------------------
.[0m.[96mTotal .[0m.[96m .[0m.[96m 142.18.[0m.[96m 153.28.[0m.[96m 205/0/0.[0m.[96m 5.3T.[0m.[96m 0.277.[0m.[96m
.[0m.[96m
.[0m.[96m .[0m.[96m Power.[0m.[96m CCLK.[0m.[96m MCLK.[0m.[96m Core.[0m.[96m Junc.[0m.[96m Mem.[0m.[96m Fan.[0m.[96m
.[0m.[96m .[0m.[96m W.[0m.[96m MHz.[0m.[96m MHz.[0m.[96m Temp.[0m.[96m Temp.[0m.[96m Temp.[0m.[96m Pct.[0m.[96m
.[0m.[96mGPU 0 .[0m.[96m 192.2.[0m.[96m 2062.[0m.[96m 5005.[0m.[96m 44.[0m.[96m 58.[0m.[96m N/A.[0m.[96m 65.[0m.[96m
.[0m.[96mGPU 1 .[0m.[96m 206.2.[0m.[96m 1999.[0m.[96m 4865.[0m.[96m 56.[0m.[96m 70.[0m.[96m N/A.[0m.[96m 94.[0m.[96m
.[0m.[96mGPU 2 .[0m.[96m 65.6.[0m.[96m 1050.[0m.[96m 7787.[0m.[96m 42.[0m.[96m 58.[0m.[96m 58.[0m.[96m 67.[0m.[96m
.[0m.[96mGPU 3 .[0m.[96m 47.9.[0m.[96m 1372.[0m.[96m 890.[0m.[96m 45.[0m.[96m 47.[0m.[96m 52.[0m.[96m 72.[0m.[96m
.[0m.[96m---------------------------
.[0m.[96mTotal .[0m.[96m 511.9.[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m .[0m.[96m
.[0m.[96m---------------------------------------------
.[0mAverage speed (10s): 43.61 Mh/s | 42.69 Mh/s | 32.22 Mh/s | 0.00 Mh/s Total: 118.52 Mh/s
.[93mNew job received: 0xd5f5f9 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xbbb4a1 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xa816b3 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0x3251e7 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0x23c5b7 Epoch: 489 Difficulty: 17.45G
.[0mAverage speed (10s): 43.62 Mh/s | 42.67 Mh/s | 32.22 Mh/s | 0.00 Mh/s Total: 118.52 Mh/s
.[93mNew job received: 0x174c08 Epoch: 489 Difficulty: 17.45G
.[0m.[92mGPU 0: Found a share of difficulty 66.29G
.[0m.[92mGPU 0: Share accepted (48 ms)
.[0mAverage speed (10s): 43.63 Mh/s | 42.69 Mh/s | 32.22 Mh/s | 0.00 Mh/s Total: 118.53 Mh/s
.[93mNew job received: 0x0155d4 Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0x96c560 Epoch: 489 Difficulty: 17.45G
.[0mAverage speed (10s): 43.61 Mh/s | 42.68 Mh/s | 32.22 Mh/s | 0.00 Mh/s Total: 118.51 Mh/s
.[93mNew job received: 0xe8cc8f Epoch: 489 Difficulty: 17.45G
.[0m.[93mNew job received: 0xe5a2d2 Epoch: 489 Difficulty: 17.45G
.[0m.[31mDevice 3 detected as crashed.
.[0m.[31mClosing miner and trying to call external script: ./emergency.sh (–watchdog script)

Rx 5600xt
Rx 5600xt1801Ă—85 21.4 KB

#2

Switch to teamredminer, and what voltages are you trying to set that it’s crashing right away?

#3

It will crash after few minutes if i set the VDDCI and MVDD less than 850 mv and 1350mv respectively

#4

I had the same “XXXXX’s”, flashed bios (google this) and I get 43 MH/s with on Teamredminer. 1130 700700/1300 930

#5

Could you upload the bios please ?

#6

follow Red panda’s info

#7

also I had to tune them down a bit; they have been running stable for months now;

image1235Ă—222 28.6 KB

1 Like
#8

Thank you for your answer
Red panda’s bios made it worse, only giving 36mh, so back to stock , and the max memory overclock is 840mhz, 10mhz more and it will crash after few hours.

#9
